| Frame | aluminium 6061, Steckachse X-12 (1.00) x 148mm, disc brake Post Mount, Travel: 20mm |
|---|
| Drive unit | Yamaha PW-ST System, 250W, 70Nm, 25km/h |
|---|
| Display | Yamaha Side Switch 1.7" LCD, 7 functions |
|---|
| Battery | InTube, 630 Wh |
|---|
| Charger | Schnellladegerät 4A |
|---|
| Fork | RockShox Revelation RC, air, Travel: 120mm, aluminium steerer tube 1 1/8" - 1 1/2" tapered, thru-axle Boost |
|---|
| Shifting system | Shimano Deore XT M8100 Shadow Plus, 12 speed |
|---|
| Gear lever | Shimano Deore M6100, trigger switch |
|---|
| Rear sprocket | Shimano HG6100, 10-51 teeth |
|---|
| Chain | Shimano CN-M6100 |
|---|
| Chain ring | 38, steel |
|---|
| Chain guide | Nylon directmount |
|---|
| Brake lever | Shimano M6100, aluminium |
|---|
| Front brake | Shimano M6100, 203mm, aluminium, 4-piston disc brake |
|---|
| Rear brake | Shimano M6100, 180mm, aluminium, 4-piston disc brake |
|---|
| Tyres | Schwalbe Nobby Nic Evo, 70-584 |
|---|
| Rims | Rodi Tryp 30, with eylets, hollow rim, aluminium |
|---|
| Front wheel hub | Shimano MT400-B Steckachse 15x110mm |
|---|
| Rear wheel hub | Shimano MT410 Steckachse 12x148mm |
|---|
| Spokes | Sapim Leader, black |
|---|
| Handlebar | XLC Topflat 740mm |
|---|
| Grips | XLC MTB grips |
|---|
| Stem | XLC Alu, A-head |
|---|
| Head set | A-Head Tapered, Cartridge, aluminium |
|---|
| Saddle | XLC MTB |
|---|
| Seat post | Dropper-Post Remote 31.6, telescope, 31.6mm, aluminium |
|---|
| Pedals | Freeridepedal mit Reflektor, aluminium |
|---|
| Total perm. weight | 120kg |
|---|
| Wheel size | 27.5" |
|---|
