| Frame | aluminium 6061, Modular Rail System (MRS), Steckachse M12 (1.00) x 148mm, disc brake Post Mount, Travel: 120mm |
|---|
| Drive unit | Bosch Performance CX GEN4, 250W, 85Nm, 25km/h |
|---|
| Display | Bosch Purion |
|---|
| Battery | Bosch PowerTube, 625 Wh |
|---|
| Charger | Bosch Standard Charger 4A |
|---|
| Fork | RockShox 35 Silver, steel spring, Travel: 120mm, Aluschaft 1 1/8 - 1 1/2'' tapered, thru-axle Boost |
|---|
| Shifting system | Shimano Deore M5100, 11 speed |
|---|
| Gear lever | Shimano Deore M5100, trigger switch |
|---|
| Rear sprocket | Shimano HG5100, 11-51 teeth |
|---|
| Chain | KMC X11 |
|---|
| Chain ring | 38, steel |
|---|
| Chain guide | Haibike aluminium/Nylon directmount |
|---|
| Brake lever | Shimano MT401, aluminium |
|---|
| Front brake | Shimano MT420, 203mm, aluminium, 4-piston disc brake |
|---|
| Rear brake | Shimano MT420, 180mm, aluminium, 4-piston disc brake |
|---|
| Tyres | Schwalbe Nobby Nic Evo, 70-584 |
|---|
| Rims | Rodi Tryp 35, with eylets, hollow rim, aluminium |
|---|
| Front wheel hub | Shimano MT400-B Steckachse 15x110mm |
|---|
| Rear wheel hub | Shimano MT400-B Steckachse 12x148mm |
|---|
| Spokes | Sapim Leader, black |
|---|
| Handlebar | Haibike Components TheBar + Topflat 720mm |
|---|
| Grips | Haibike MTB grips |
|---|
| Stem | Haibike Components TheStem ++, A-head, Bar bore: 31.8mm, 7° |
|---|
| Head set | A-Head Tapered, Cartridge, aluminium |
|---|
| Saddle | XLC MTB |
|---|
| Seat post | Haibike Components TheSeatpost ++, patent, 34.9mm, aluminium |
|---|
| Pedals | Freeridepedal mit Reflektor, aluminium |
|---|
| Total perm. weight | 120kg |
|---|
| Wheel size | 27.5" |
|---|
